外行人也許要問：仿威圖機柜是個啥？有些行內人也許并不十分清楚：威圖，仿威圖機柜與一般機柜的區別在哪里？小途途先回答外行人的問題：

　　Outsiders may ask: What is the imitation Weitu cabinet? Some industry insiders may not be very clear: What is the difference between Weitu, imitation Weitu cabinets and general cabinets? Xiaotu, first answer the question from outsiders:

　　仿威圖機柜，望文生義，即仿造德國威圖公司的機柜。怎么辨別仿威圖機柜與一般機柜差異呢？

　　Imitation of Rittal cabinets, literally means imitating the cabinets of the German company Rittal. How to distinguish the differences between imitation Weitu cabinets and general cabinets?

　　，我們來說說威圖公司原創威圖機柜特色：

　　Firstly, let's talk about the unique features of the original Weitu cabinet from Weitu Company:

　　一、威圖柜的特色即是威圖柜是選用型材構造框架，先將柜子的構造焊接好，然后頂板、底板、側板、門板、裝置板用螺絲固定在構造上，這樣的優點即是商品模塊化構造，運用便利；

　　1、 The biggest feature of the Weitu cabinet is that it uses profiles to construct the frame. The cabinet structure is first welded, and then the top plate, bottom plate, side plate, door panel, and device plate are fixed to the structure with screws. This advantage is the modular structure of the product, which is convenient to use;

　　威圖柜從構造上（機柜框架使用型材不同）可分為三大系列，ES柜（五折型材柜），PS柜（九折型材柜），TS柜（十六折型材柜）。為了照顧一下外行以及不怎么內行的讀者心情，這里普及一下威圖柜使用的型材：以常用的PS柜框架使用的九折型材為例，尺寸厚度形狀見下圖：

　　Weitu cabinets can be divided into three major series in terms of structure (with different profiles used for cabinet frames): ES cabinets (five fold profile cabinets), PS cabinets (nine fold profile cabinets), and TS cabinets (sixteen fold profile cabinets). To cater to the needs of novice and less knowledgeable readers, here is a brief introduction to the profiles used in Weitu cabinets: taking the commonly used PS cabinet frame with a nine fold profile as an example, the dimensions, thickness, and shape are shown in the following figure:

　　九折型材工藝特點及性能：

　　Process characteristics and performance of nine fold profiles:

　　1.九折型材是通過九次輥壓冷軋成型的一種型材，其結構合理，穩定性高，承重量大。

　　1. Nine fold profile is a type of profile formed by nine rounds of cold rolling, with a reasonable structure, high stability, and large load-bearing capacity.

　　2.采用九折型材后的機柜擁有更大的內部可用空間，柜角周圍，上下前后左右皆可并柜。可兼容所有的PS4000附件，與威圖所有新產品、附件系統標準統一。雙層框架結構——可以實現達15%的空間擴展，內外層框架之間可以布線或者安裝新型的部件。

　　2. The cabinet with nine fold profiles has a larger available internal space, and can be combined around the cabinet corners, up, down, front, back, left, and right. Compatible with all PS4000 accessories and unified with all new products and accessory system standards of Weitu. Double layer frame structure - can achieve up to 15% space expansion, and new components can be wired or installed between the inner and outer frames.

　　3.應用范圍：上下底蓋框架型材、立柱型材、門板加強方管，側橫檔（安裝軔）、等各種附件，機柜制作商只需制作門板、側板和頂蓋，節省了各機柜制作商的制作周期，降低成本。

　　3. Application scope: Various accessories such as upper and lower bottom cover frame profiles, column profiles, door panel reinforced square tubes, side rails (installation rails), etc. Cabinet manufacturers only need to produce door panels, side panels, and top covers, saving the production cycle of each cabinet manufacturer and reducing costs.

　　4.九折型材的框架相比PS4000重量減輕15%，穩定性提高30%。可以承受超過1000公斤的重量

　　The frame of the nine fold profile reduces weight by 15% and improves stability by 30% compared to the PS4000. Can withstand weights exceeding 1000 kilograms

　　TS柜使用的十六折型材如下圖：

　　The 16 fold profile used in the TS cabinet is shown in the following figure:

　　二、商品美觀，rittal機柜從工業品的運用和外觀上都尋求完滿的理念，從鈑金構造規劃和附件的調配運用也非常合理科學，形成了標準化的配套規劃；

　　2、 The product is aesthetically pleasing, and Rittal cabinets seek the concept of perfection in both the application and appearance of industrial products. The sheet metal structure planning and accessory allocation are also very reasonable and scientific, forming a standardized supporting plan;

　　三、運用便利，內部的縱梁、立柱、橫梁、走線條及自身的模塑化孔的規劃使得用戶裝置都顯得得心應手、便利自若；四、健壯耐用、可靠，威圖柜構造構造使得構造穩固，單柜可承重2000KG，不懼裝置任何粗笨器材；五、威圖柜從使用材料上，分為碳鋼和不銹鋼。料厚默許為門板2.0mm，裝置板2.5mm，柜體1.5mm；六、碳鋼的外表處理默許為噴塑處理，噴塑前做磷化底涂處理，色彩為RAL7035，不銹鋼的外表處理默許技術為拉絲處理。

　　3、 Convenient to use, the internal longitudinal beams, columns, crossbeams, lines, and the planning of its own molded holes make the user device appear effortless and convenient; 4、 Robust, durable, safe and reliable, the construction of the Weitu cabinet ensures stability. The maximum load-bearing capacity of a single cabinet is 2000KG, and it is not afraid of installing any bulky equipment; 5、 Weitu cabinets are divided into carbon steel and stainless steel based on the materials used. The material thickness is allowed to be 2.0mm for door panels, 2.5mm for device boards, and 1.5mm for cabinet bodies. The surface treatment of carbon steel is allowed to be spray coating, with phosphating primer treatment before spray coating and RAL7035 color. The surface treatment of stainless steel is allowed to be wire drawing treatment.

　　威圖公司生產的機柜非常高，國內有些工廠拷貝威圖的技術，做出的機柜就是仿威圖柜。國內有的廠家做出的仿威圖機柜在技術水平上已經趕上或挨近正品威圖rittal，一起在貨期、效勞、報價上相比威圖有很大的優勢。? ?? 而一般柜子為鐵皮焊接，對板材需求和加工的平整度，配件選擇都沒有嚴格需求，構造也八成為固定焊接處理，運用起來不靈敏。當然報價也相對廉價許多。

　　The price of cabinets produced by Weitu Company is very high. Some domestic factories copy Weitu's technology and make cabinets that are imitations of Weitu cabinets. Some domestic manufacturers have already caught up with or approached the technical level of genuine Vitu Rittal in producing imitation Vitu cabinets, which have significant advantages in terms of delivery time, service, and pricing compared to Vitu. However, most cabinets are welded with iron sheets, and there are no strict requirements for the flatness of the sheet metal and the selection of accessories. The structure is also fixed and welded, making it less sensitive to use. Of course, the quotation is also relatively cheaper.

　　本文由山東仿威圖機柜   友情奉獻.更多有關的知識請點擊  http://www.baidu-guiyang.com/   真誠的態度.為您提供為的服務.更多有關的知識我們將會陸續向大家奉獻.敬請期待.
